Technical data
26 8LS...-3 user's manual V2.50
2.8.2 Availability - Single-cable solution (hybrid) (ff) 8LSA / 8LSC
The single-cable solution (hybrid) is only possible for motors with connector size 1.0
(built-in connector on the motor side) and therefore generally up to size/length 65.
The following exceptions apply to individual motors with size/length 5A, 5B and 5C. The
listed motors are therefore not available as a single-cable solution (hybrid).
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSA5A.ee045ffgg-3 4500 1.5 ---
8LSA5B.ee030ffgg-3 3000 1.5 ---
8LSA5B.ee040ffgg-3 4000 1.5 ---
8LSA5C.ee022ffgg-3 2200 1.5 ---
8LSA5C.ee030ffgg-3
A
3000 1.5 ---
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSC5A.ee045ffgg-3 4500 1.5 ---
8LSC5B.ee030ffgg-3 3000 1.5 ---
8LSC5B.ee040ffgg-3 4000 1.5 ---
8LSC5C.ee022ffgg-3 2200 1.5 ---
8LSC5C.ee030ffgg-3
C
3000 1.5 ---
Availability - 8LSA66 / 8LSC66
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSA66.ee015ffgg-3 1500 1 Yes
8LSA66.ee022ffgg-3 2200 1 Yes
8LSA66.ee030ffgg-3 3000 1 Yes
8LSA66.ee045ffgg-3
A
4500 1.5 ---
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSC66.ee015ffgg-3 1500 1 Yes
8LSC66.ee022ffgg-3 2200 1 Yes
8LSC66.ee030ffgg-3 3000 1 Yes
8LSC66.ee045ffgg-3
C
4500 1.5 ---
Availability - 8LSA7 / 8LSC7
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSA73.ee030ffgg-3 3000 1 Yes
8LSA73.ee045ffgg-3 4500 1.5 ---
8LSA74.ee015ffgg-3 1500 1 Yes
8LSA74.ee020ffgg-3 2000 1 Yes
8LSA74.ee022ffgg-3 2200 1 Yes
8LSA74.ee030ffgg-3 3000 1 Yes
8LSA74.ee045ffgg-3 4500 1.5 ---
8LSA75.ee015ffgg-3 1500 1 Yes
8LSA75.ee020ffgg-3 2000 1 Yes
8LSA75.ee022ffgg-3 2200 1 Yes
8LSA75.ee030ffgg-3 3000 1 Yes
8LSA76.ee015ffgg-3 1500 1.5 ---
8LSA76.ee030ffgg-3
A
3000 1.5 ---
Cooling type Speed Connector size Single-cable solution (hybrid) available
8LSC73.ee030ffgg-3 3000 1 Yes
8LSC73.ee045ffgg-3 4500 1.5 ---
8LSC74.ee020ffgg-3 2000 1 Yes
8LSC74.ee022ffgg-3 2200 1 Yes
8LSC74.ee030ffgg-3 3000 1 Yes
8LSC74.ee045ffgg-3 4500 1.5 ---
8LSC75.ee030ffgg-3 3000 1.5 ---
8LSC76.ee030ffgg-3
C
3000 1.5 ---
All other lengths for size 7 are equipped with connector size 1.5 and therefore not available for the single-cable
solution (hybrid).
Availability - 8LSA8 / 8LSC8
Size 8 motors (connector size 1.5) are not available for the single-cable solution (hybrid).
Motor options (ff) - Overview (order code)
see "Motor options (ff) 8LSA / 8LSC" on page 24
