Technical data
150 8LS...-3 user's manual V2.50
2.14.9 8LSA8...-3 - Technical data
Model number 8LSA83.ee015ffgg-3 8LSA83.ee022ffgg-3 8LSA83.ee030ffgg-3 8LSA84.ee015ffgg-3
Motor
Nominal speed n
N
[rpm] 1500 2200 3000 1500
Number of pole pairs 3
Nominal torque M
n
[Nm] 35 31 27 58
Nominal power P
N
[W] 5498 7142 8482 9111
Nominal current I
N
[A] 10.7 14 16.6 17.8
Stall torque M
0
[Nm] 40 69
Stall current I
0
[A] 12.3 18 24.5 21.2
Maximum torque M
max
[Nm] 120 204
Maximum current I
max
[A] 50 72.6 102 79
Maximum speed n
max
[rpm] 3600
Torque constant K
T
[Nm/A] 3.26 2.22 1.63 3.26
Voltage constant K
E
[V/1000 rpm] 196.87 134.04 98.44 196.87
Stator resistance R
2ph
[Ω] 0.896 0.41 0.23 0.34
Stator inductance L
2ph
[mH] 16.86 9.6 5.4 10.3
Electrical time constant t
el
[ms] 18.8 23.4 23.5 30.3
Thermal time constant t
therm
[min] 50 65
Moment of inertia J [kgcm
2
] 65 114
Weight without brake m [kg] 43 61
Holding brake
Holding torque of brake M
Br
[Nm] 130
Mass of brake [kg] 9
Moment of inertia of brake J
Br
[kgcm
2
] 53
Recommendations
ACOPOS 8Vxxxx.xx... 1180 1320
ACOPOSmulti 8BVIxxxx... 0110 0220 0330
ACOPOS P3 8EIxxxx... 017X 024X 034X 024X
Cross section for B&R motor cables
[mm
2
]
4
Connector size 1.5
NOTE about servo drives: The recommended servo drive / inverter module is designed for 1.1x the stall current. If more than double the amount is needed during
the acceleration phase, the next larger servo drive should be selected. This recommendation is only a guideline; detailed inspection of the corresponding speed/
torque characteristic curve can result in deviations of the servo drive size (larger or smaller).
NOTE about cable cross section: The B&R motor cables with this cable cross section are produced optimally (cables stripped to the correct length) for the
ACOPOS servo drive or the recommended ACOPOS inverter module. B&R motor cables with other cable cross sections can also be used (within the specified
terminal cross section range) and can be obtained from B&R in the desired design on request. Note the type of wiring.
