Technical data
8LS...-3 user's manual V2.50 27
2.8.3 Oil seal (ff) 8LSA / 8LSC
All 8LS three-phase synchronous motors are available with a form A oil seal per DIN 3760.
When equipped with an oil seal, the motors have IP65 protection per EN 60034-5.
Motor options (ff) - Overview (order code)
see "Motor options (ff) 8LSA / 8LSC" on page 24
Servicing
To maintain functionality of the oil seal, it must be lubricated regularly with oil. An oil seal that is not lubricated will
harden due to increased frictional heat and will eventually provide only dust protection.
Note:
Proper lubrication of the oil seal must be ensured throughout the entire service life of the motor.
For this reason, mounting a gearbox on motors with an oil seal is not permitted!
