Technical data
8LS...-3 user's manual V2.50 43
2.13.1 8LSA25...-3 - Standard motors
Nominal speed nN [rpm] Resolver EnDat (inductive)
Holding
brake
Connection direction Shaft end
8LSA25.R0060D000-3 --- ---
8LSA25.R0060D200-3 --- Yes
Smooth shaft
8LSA25.R0060D100-3 --- ---
8LSA25.R0060D300-3
R0
--- Yes
Angled (swivel connector)
Keyed shaft
8LSA25.D8060S000-3 --- ---
8LSA25.D8060S200-3 ---
2.2 single-turn
Yes
8LSA25.D9060S000-3 --- ---
8LSA25.D9060S200-3 ---
2.2 multi-turn
Yes
Smooth shaft
8LSA25.D8060S100-3 --- ---
8LSA25.D8060S300-3 ---
2.2 single-turn
Yes
8LSA25.D9060S100-3 --- ---
8LSA25.D9060S300-3
6000
---
2.2 multi-turn
Yes
Single-cable solution (hybrid)
Angled, swivel connector
Keyed shaft
8LSA25...-3 - Technical data
Model number 8LSA25.ee060ffgg-3
Motor
Nominal speed n
N
[rpm] 6000
Number of pole pairs 4
Nominal torque M
n
[Nm] 0.52
Nominal power P
N
[W] 327
Nominal current I
N
[A] 0.71
Stall torque M
0
[Nm] 0.6
Stall current I
0
[A] 0.82
Maximum torque M
max
[Nm] 2.4
Maximum current I
max
[A] 3.7
Maximum speed n
max
[rpm] 9000
Torque constant K
T
[Nm/A] 0.73
Voltage constant K
E
[V/1000 rpm] 43.98
Stator resistance R
2ph
[Ω] 34.63
Stator inductance L
2ph
[mH] 49.6
Electrical time constant t
el
[ms] 1.4
Thermal time constant t
therm
[min] 20
Moment of inertia J [kgcm
2
] 0.16
Weight without brake m [kg] 1.3
Holding brake
Holding torque of brake M
Br
[Nm] 2.2
Mass of brake [kg] 0.45
Moment of inertia of brake J
Br
[kgcm
2
] 0.12
Recommendations
ACOPOS 8Vxxxx.xx... 1010
ACOPOSmulti 8BVIxxxx... 0014
ACOPOS P3 8EIxxxx... 2X2X
Cross section for B&R motor cables [mm
2
] 0.75
Connector size 1.0
Additional technical data
Speed-torque characteristic curve, permissible shaft load and dimensions
see "8LSA2...-3 - Technical data" on page 51
