Technical data
8LS...-3 user's manual V2.50 21
Available encoders / Order code (ee)
Availability
E0 E1 D0 D1 S0 S1
8LSx2...-3 --- --- --- --- --- ---
8LSx3/4/5/6/7/8...-3
8LSx5A/B/C...-3
Yes Yes Yes Yes Yes Yes
8LSO...-3
8LSP...-3
--- --- Yes Yes --- ---
2.7 Nominal speed (nnn)
8LS b c d . ee nnn ff gg - h see "Order key" on page 13
8LS three-phase synchronous motors are available with different nominal speeds.
The nominal speed is listed as part of the model number in the form of a 3-digit code (nnn).
Order code (nnn)
011 013 015 020 022 030 040 045 060
Nominal speed n
N
[rpm] 1100 1300 1500 2000 2200 3000 4000 4500 6000
2.7.1 Availability - 8LSA...-3
8LSA2
Available nominal speeds n
N
[rpm]
1100 1300 1500 2000 2200 3000 4000 4500 6000
8LSA23 --- --- --- --- --- --- --- --- Yes
8LSA24 --- --- --- --- --- --- --- --- Yes
8LSA25 --- --- --- --- --- --- --- Yes Yes
8LSA26 --- --- --- --- --- --- --- Yes Yes
8LSAA
Available nominal speeds n
N
[rpm]
1100 1300 1500 2000 2200 3000 4000 4500 6000
8LSAA --- --- --- --- --- Yes --- Yes Yes
8LSA3
Available nominal speeds n
N
[rpm]
1100 1300 1500 2000 2200 3000 4000 4500 6000
8LSA33 --- --- --- --- --- Yes --- Yes Yes
8LSA34 --- --- --- --- Yes Yes --- Yes Yes
8LSA35 --- --- --- --- Yes Yes --- Yes Yes
8LSA36 --- --- --- --- Yes Yes --- Yes Yes
8LSA37 --- --- --- --- Yes Yes --- Yes Yes
8LSA4
Available nominal speeds n
N
[rpm]
1100 1300 1500 2000 2200 3000 4000 4500 6000
8LSA43 --- --- --- --- Yes Yes --- Yes Yes
8LSA44 --- --- --- --- Yes Yes --- Yes Yes
8LSA45 --- --- --- --- Yes Yes --- Yes Yes
8LSA46 --- --- --- --- Yes Yes --- Yes Yes
8LSA5
Available nominal speeds n
N
[rpm]
1100 1300 1500 2000 2200 3000 4000 4500 6000
8LSA53 --- --- --- --- Yes Yes --- Yes ---
8LSA54 --- --- --- --- Yes Yes --- Yes ---
8LSA55 --- --- --- --- Yes Yes --- Yes ---
8LSA56 --- --- --- --- Yes Yes --- Yes ---
8LSA57 --- --- --- --- Yes Yes --- Yes ---
8LSA5A --- --- --- --- Yes Yes --- Yes ---
8LSA5B --- --- --- --- Yes Yes Yes --- ---
8LSA5C --- --- Yes --- Yes Yes --- --- ---
