Technical data
198 8LS...-3 user's manual V2.50
2.15.3.5 8LSC5A/B/C...-3 - Dimensions
Motor
EnDat/Resolver feedback Extension of K
0
and M depending on motor option [mm]
K
0
M Holding brake Increased brake Reinforced bearing
Encoder assign-
ments
All encoders All encoders
Connector size 1 1.5
8LSC5A...-3 358 227 229.5 38 60 17
8LSC5B...-3 425.5 294.5 297 --- 60 17
8LSC5C...-3 493 362 364.5 --- 60 17
IMPORTANT: Dimension K
0
depends on the length of the encoder cover.
Shaft end
D L Key CH X
8LSC5A...-3 Without special motor option
Reinforced bearing
24 k6
38 k6
50
80
DIN 6885 A8x7x40
DIN 6885 A10x8x70
M8 DIN 332-D
M12 DIN 332-D
5
5
8LSC5B...-3 Without special motor option
Reinforced bearing
28 k6
38 k6
58
80
DIN 6885 A8x7x40
DIN 6885 A10x8x70
M10 DIN 332-D
M12 DIN 332-D
9
5
8LSC5C...-3 Without special motor option
Reinforced bearing
28 k6
38 k6
58
80
DIN 6885 A8x7x40
DIN 6885 A10x8x70
M10 DIN 332-D
M12 DIN 332-D
9
5
