Technical data
8LS...-3 user's manual V2.50 201
2.15.4.1 Speed-torque characteristic curves at 325 VDC DC bus voltage
8LSC63.eennnffgg-3
0 500 1000 1500 2000 2500 3000 3500 4000
0
10
20
30
40
50
60
(0/47)
(695/47)
(1699/0.2)
(0/16.3)
(0/47)
(1040/47)
(2337/0)
(0/16.3)
(0/47)
(1761/47)
(3487/0)
(0/16.3)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60K
n
N
= 2200 min
-1
n
N
= 3000 min
-1
n
N
= 4500 min
-1
Speed [rpm]
Torque [Nm]
8LSC64.eennnffgg-3
0 500 1000 1500 2000 2500 3000 3500 4000
0
10
20
30
40
50
60
70
80
90
(0/78.2)
(773/78.2)
(1699/0.4)
(0/26)
(0/78.2)
(1087/78.2)
(2337/0)
(0/26)
(0/78.2)
(1709/78.2)
(3487/0)
(0/26)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60K
n
N
= 2200 min
-1
n
N
= 3000 min
-1
n
N
= 4500 min
-1
Speed [rpm]
Torque [Nm]
8LSC65.eennnffgg-3
0 500 1000 1500 2000 2500 3000 3500 4000
0
20
40
60
80
100
120
(0/98)
(738/98)
(1716/0)
(0/31.2)
(0/98) (1075/98)
(2337/0)
(0/31.2)
(0/98) (1761/98)
(3487/0)
(0/31.2)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60K
n
N
= 2200 min
-1
n
N
= 3000 min
-1
n
N
= 4500 min
-1
Speed [rpm]
Torque [Nm]
