B&R 8LS 3 Series User Manual

Technical data
52 8LS...-3 user's manual V2.50
2.14.1.1 Speed-torque characteristic curves at 325 VDC DC bus voltage
8LSA23.eennnffgg-3
0 1000 2000 3000 4000 5000 6000
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
(0/0.8)
(785/0.8)
(5099/0.1)
(0/0.2)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60KdT ... 60K
n
N
= 6000 min
-1
Speed [rpm]
Torque [Nm]
8LSA24.eennnffgg-3
0 1000 2000 3000 4000 5000 6000
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
(0/1.6)
(1700/1.6)
(5230/0)
(0/0.4)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60KdT ... 60K
n
N
= 6000 min
-1
Speed [rpm]
Torque [Nm]
8LSA25.eennnffgg-3
0 1000 2000 3000 4000 5000 6000
0
0.5
1
1.5
2
2.5
3
(0/2.4)
(844/2.4)
(3923/0)
(0/0.6)
(0/2.4)
(1595/2.4)
(5178/0.1)
(0/0.6)
TChar Version:0124
DB Version:2018 06 12
dT ... 100K
dT ... 60K
n
N
= 4500 min
-1
n
N
= 6000 min
-1
Speed [rpm]
Torque [Nm]
