7.3 Create RAID set - Mirrored
Auto Configuration
Auto Configuration optimizes all settings.
Manual Configuration
It is possible to specify the "Source" and "Target" HDD, and also to specify whether a rebuild
(mirror) should be performed immediately (approx. 50 minutes).
Figure 129: RAID Configuration Utility - Create RAID set - Mirrored
RAID Configuration Utility - Silicon Image Inc. Copyright (C) 2006
Press "Enter" to automatica-
Manual Configuration lly create a mirrored
*0PM
1SM
Select Menu
ESC Previous Menu
Enter Select
Ctrl-E Exit
* First HDD
(RAID 1) set
For migrating single HDD
into RAID 1 set, use Manual
configuration instead
ST96023AS 55GB
ST96023AS 55GB
Auto Configuration
