B&R MAPPC700A-ENG - Panel PC 5 PC720.1906-00

Technical data • Individual components
Chapter 2
Technical data
143Panel PC 700 with 945GME N270 CPU board User's Manual V 1.16
3.1.9 Panel PC 5PC720.1906-00
Figure 69: Front view 5PC720.1906-00
Figure 70: Rear view 5PC720.1906-00
O
p
e
n
C
l
o
s
e
USB connection on front
VOID WARRANTY
IF SEAL BROKEN
LED for
Power, HDD
Link1
COM1
COM2
Hardware security
key (dongle)
Ethernet2
(ETH2)
USB1, USB2
Voltage supply + 24 VDC
MIC, Line IN,
Line OUT
Add-on
interface slot
Ethernet1
(ETH1)
Battery
PS/2 keyboard or
PS/2 mouse
Reset
button
Power
button
CompactFlash
slot (Cf1)
Add-on drive slot
(HDD / Cf2)
Heat sink
Monitor/Panel
SDL (Smart Display Link) / DVI
