Appendix A • Touch Screen - Elo Accu Touch
Appendix A
481Panel PC 700 with 945GME N270 CPU board User's Manual V 1.16
6.1 Temperature humidity diagram
Temperature data is for operation at 500 meters. Derating the max. ambient temperature -
typically 1°C per 1000 meters (from 500 meters above sea level).
6.2 Cleaning
The touch screen should be cleaned with a moist lint-free cloth. When moistening the cloth, use
only water with detergent, screen cleaning agent, or alcohol (ethanol). The cleaning agent
should be applied to the cloth beforehand and not sprayed directly onto the touch screen itself.
Never use aggressive solvents, chemicals, or scouring agents.
Figure 280: Temperature humidity diagram - Elo Accu touch screen 5-wire
0102030405060708090-80 -70 -60 -50 -40 -30 -20 -10
5
10
100
95
90
85
80
75
70
65
60
55
50
45
40
35
30
25
20
15
Temperature [°C]
+
-
Relative humidity [%RH] (non-condensing)
Storage
0
Operation
