Technical data • Entire device
Chapter 2
Technical data
83Panel PC 700 with 945GME N270 CPU board User's Manual V 1.16
2.4.10 PCI slots
Up to 2 PCI slots are available, depending on the system unit. 5 volt cards and universal cards
that comply with the PCI half-size standard 2.2 and do not exceed the following dimensions can
be inserted.
Technical data
Figure 32: Dimensions - Standard half-size PCI cards
Information:
The total performance of one PCI card per PCI slot should not exceed the limit with
or without a fan kit (see section 2.3 "Power management").
Features PCI bus properties
Standard PCI 2.2
Design Half-size PCI
PCI bus type 32-bit
PCI bus speed 33 MHz
Table 39: Technical data - PCI bus
177.7
106.7
9
25.8
9
5517.4
100.5
