Accessories • USB flash drive
Chapter 6
Accessories
409Panel PC 700 with 945GME N270 CPU board User's Manual V 1.16
14.3.1 Temperature humidity diagram
Temperature data is for operation at 500 meters. Derating the max. ambient temperature -
typically 1°C per 1000 meters (from 500 meters above sea level).
Environmental characteristics 5MMUSB.2048-00
Altitude
Operation
Storage
Transport
3,048 meters
12,192 meters
12,192 meters
Figure 215: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-00
Table 227: Technical data - USB flash drive 5MMUSB.2048-00 (Forts.)
0
0102030405060708090-80 -70 -60 -50 -40 -30 -20 -10
5
10
100
95
90
85
80
75
70
65
60
55
50
45
40
35
30
25
20
15
Temperature [°C]
+
-
Relative humidity [%RH] (non-condensing)
Operation
Storage
Transport
