12 Power Panel User's Manual
Power Panel • Power Panel PP21
5. Power Panel PP21
5.1 Order Data
Model Number Short Description
Power Panel
4P0420.00-490
1)
1) All parts required to install the Power Panel, including key legend sheets, are included in its delivery. The backup battery and the 4 pin
terminal block for the supply are also included. Two 12 pin terminal blocks must be ordered separately.
Power Panel PP21, LC display 4x20 characters, background lighting, 34 function keys,
system compatible 2003 CPU, 700Kb SRAM, 1.4MB FlashPROM, 1 PCMCIA slot, 1
RS232 interface, 1 CAN interface: electrically isolated, network capable, 6 slots for screw-
in modules, 10 digital inputs 24 VDC, 8 digital outputs 24 VDC, 0.4 A, IP65 protection (from
front), 155 x 190 mm (WxH), 24 VDC, Order TB712 terminal blocks separately!
Accessories
0AC201.9 Lithium batteries, 5 pcs., 3 V / 950 mAh, button cell
0MC111.9 PCMCIA memory card, 2MB FlashPROM
0MC211.9 PCMCIA memory card, 2MB SRAM
4A0035.00-000 Set of legend strips for 4P0420.00-490 (for 10 devices)
7TB712.9 Terminal block, 12 pin, screw clamps
7TB712.91 Terminal block, 12 pin, cage clamps
7TB712:90-02 Terminal block, 12 pin, 20 pcs., screw clamps
7TB712:91-02 Terminal block, 12 pin, 20 pcs., cage clamps
Table 3: Order data for the Power Panel PP21
