Power Panel User's Manual 33
Chapter 1
Power Panel
Power Panel • Device Label
10. Device Label
The assignment for the plugs and the pin connectors are indicated on the device label.
11. Programming
11.1 Programming the PLC CPU
Programming the PLC CPU is done using Automation Studio™ or PG2000. Several
programming languages are available.
11.2 Visualization
The visualization application is created using B&R Automation Studio™.
Figure 15: Device label
Automation Studio™ PG2000
Automation Basic (previously PL2000) Instruction List (IL)
ANSI C Ladder Diagram (LAD)
IEC 1131 Ladder Diagram (LAD) PL2000 High Level Language (structured text)
IEC 1131 Sequential Function Chart (SFC)
IEC 1131 Structured Text (ST)
IEC 1131 Instruction List (IL)
Table 14: Programming languages
