Power Panel User's Manual 27
Chapter 1
Power Panel
Power Panel • Power Panel Expansion EX101 Module
7.4 Technical Data
7.5 Images
Product ID EX101
General Information
Module Type Power Panel expansion for PP41
Peripherals
Insert Slots 1 (for interface module inserts)
Mechanical Characteristics
Dimensions
Width
Height
Depth
31 mm
173 mm
81.4 mm
Table 9: Technical data for EX101
View from above View from below
Figure 9: EX101
