Power Panel User's Manual 19
Chapter 1
Power Panel
Power Panel • Power Panel PP41
6. Power Panel PP41
6.1 Order Data
Model Number Short Description
Power Panel
4P3040.00-490
1)
1) All parts required to install the Power Panel, including key legend sheets, are included in its delivery. The backup battery and the 4 pin
terminal block for the supply are also included. Two 12 pin terminal blocks must be ordered separately.
Power Panel PP41, 5.7 inch QVGA black/white LC display, 8 softkeys and 32 function keys,
system compatible 2003 CPU, 700 KB SRAM, 1.4 MB FlashPROM, 1 PCMCIA slot, 1
RS232 interface, 1 CAN interface: electrically isolated, network capable, 6 slots for screw-
in modules, 10 digital inputs 24 VDC, 8 digital outputs 24 VDC, 0.4 A, IP65 protection (from
front), 205 x 220 mm (WxH), 24 VDC, Order TB712 terminal blocks separately!
Accessories
0AC201.9 Lithium batteries, 5 pcs., 3 V / 950 mAh, button cell
0MC111.9 PCMCIA memory card, 2MB FlashPROM
0MC211.9 PCMCIA memory card, 2MB SRAM
4A0034.00-000 Set of legend strips for 4P3040.00-490 (für 10 Geräte)
4EX101.00 Power Panel expansion for PP41, 1 insert slot for interface module inserts
7TB712.9 Terminal block, 12 pin, screw clamps
7TB712.91 Terminal block, 12 pin, cage clamps
7TB712:90-02 Terminal block, 12 pin, 20 pcs., screw clamps
7TB712:91-02 Terminal block, 12 pin, 20 pcs., cage clamps
Table 5: Order data for PP41
