Power Panel User's Manual 13
Chapter 1
Power Panel
Power Panel • Power Panel PP21
5.2 Photo
5.3 Technical Data
Figure 2: Power Panel PP21
Product ID PP21
General Information
C-UL-US Listed In preparation
Standards
Temperature
Shock / Tests Carried Out
Vibration / Tests Carried Out
Emission / Tests Carried Out
Immunity / Tests Carried Out
IEC61131-2 / IEC60068-2-x
IEC61131-2 / IEC60068-2-27
IEC61131-2 / IEC60068-2-6
EN50081-2 / EN55022+A1
IEC61131-2 / IEC61000-4-x
Processor
Additional I/O Processor Handles I/O data points
Instruction Cycle Time
(Average value with 70% bit and
30% analog processing)
0.4 µs
Standard Memory
User RAM
System PROM
User PROM
700 Kbyte SRAM
600 KByte FlashPROM
1.4 MByte FlashPROM
Table 4: Technical data for PP21
