8.5 Status LEDs
8.6 Pin Assignments
B&R ID Code $44
Module Type B&R Power Panel screw-in module
Slot Power Panel interface, slot 1
Power Consumption TBD
Standard Communication Interface
Interface Type CAN
Electrical Isolation Interface - Power Panel
Design 9 pin DSUB plug
Status Display 2 Status LEDs
Maximum Distance 1,000 m
Maximum Baud Rate
Bus Length 10 - 60 m
Bus Length 100 -200 m
Bus Length 800 -1,000 m
Max. 500 kBit/s
Max. 250 kBit/s
Max. 50 kBit/s
Network Capable Yes
Mechanical Characteristics
Dimensions B&R Power Panel screw-in module
Lit LEDs Description
Yellow / Green Data is being sent
Green Data is being received
Table 12: IF370 status LEDs
Pin Assignment for CAN interface
Pin Assignment
9 pin DSUB connector
1NC
2CAN_L
3CAN_GND
4NC
5NC
6Reserved
7CAN_H
8NC
9NC
Table 13: Pin assignments for the IF370 CAN interface
Product ID IF370
Table 11: Technical data for the IF370
