R5906790 /04 Athena 123
2. Tighten the three retaining screws (3) of the Lamp House. Use a 7mm nut driver or a flat screw driver.
Image 13-6
3. Close the fan door (2) and tighten the retaining screw (1) of the fan door.
Image 13-7
4. Install the rear cover of the projector. See “Installation of the rear cover”, page 149.
13.4 Resetting the lamp parameters
CAUTION: The LAMP INFO parameters must be updated any time a Lamp Module is replaced.
Neglecting to do this will result in poor performance and a reduced lamp lifetime.
How to reset the lamp parameters?
1. In the Communicator software, click on Installation (1) and click on Lamp (2).
Lamp House
To Next Page
