R5906790 /04 Athena154
A.1 Specifications of the Athena
Specifications
Projector type Three chip DLP
Technology 3 x 0.69" DMD
Resolution 2,048 x 1,080 (2K)
Aspect ratio 1.89:1
Light source Dual 465W UHP Lamps
Light source lifetime TBC
Light output Up to 4,800 ANSI lumens
CLO (constant light output) Yes
Contrast ratio 1,500:1 Sequential
350:1 ANSI
Brightness uniformity 80% at sides
75% at corners
Lens range DC2K (1.20 - 1.70:1)
DC2K (1.34 - 1.90:1 )
DC2K (1.50 - 2.15:1)
DC2K (1.70 - 2.55:1)
DC2K (2.00 - 3.90:1)
DC2K HC (1.20 - 1.70:1)
DC2K HC (1.34 - 1.90:1)
DC2K HC (1.50 - 2.15:1)
DC2K HC (2.00 - 3.90:1)
Optical lens shift Up to 25% vertical lens shift & up to 15% horizontal lens shift
Motorized zoom, focus, shutter and lens shift
Tilt 15° Forwards
Backwards
Optical dowser Yes
Color correction P7
Color gamut P3 (DCI)
Image processing Alchemy - Integrated Cinema Media Processor (ICMP)
WARP N/A
Orientation Pedestal / Table Top or Ceiling Mount
Network connection 10/100 Ethernet via RJ45 connection
Software tools Barco Communicator
Integrated web server No
HDR HDR10
3D Passive Dolby system, built in (optional)
Inputs Barco Alchemy ICMP included in the projector:
2 x HDMI2.0a (up to 4K 2D 60fps)
2 x 3G-SDI inputs
Specifications
