Barco Athena User Manual

R5906790 /04 Athena 17
PR
Image 2-2
2.5 HD in function of the lens Throw Ratio (TR)
TR (Throw Ratio)
The ratio of the distance to the screen (throw) to the screen width.
Hazard Distance
HD [m]
TR
0
0,2
0,4
0,6
0,8
1
1,2
1,0 1,2 1,4 1,6 1,8 2,0 2,2 2,4 2,6 2,8 3,0 3,2 3,4 3,6 3,8 4,0 4,2 4,4 4,6
Image 2-3: HD (in meter) in function of the Throw Ratio (TR)
