SMPTE 424M 3G HD-SDI 2.970 Gb/s SIGNALS
3G HD-SDI (SMPTE 425) formats
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 296M 1280 x 720 23.976
24
25
29.970
30
50
59.940
60
23.976
24
25
29.970
30
50
59.940
60
Progressive
Y Cb Cr 4:4:4 10-Bit
RGB (XYZ) 4:4:4 10-Bit
SMPTE 274M
5
1920 x 1080 50
59.940
60
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
SMPTE 274M 1920 x 1080 23.976
24
25
29.97
30
23.976
24
25
29.97
30
Progressive
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 274M 1920 x 1080 50
59.940
60
50
59.940
60
Interlaced
Y Cb Cr 4:2:2 12-Bit only
Y Cb Cr 4:4:4 10 or 12-Bit
RGB (XYZ) 4:4:4 10 or 12-Bit
SMPTE 428-9 2048 x 1080 23.976
24
23.976
24
Progressive
Y Cb Cr 4:4:4 12-Bit
RGB (XYZ) 4:4:4 12-Bit
Dual Stream 3G HD-SDI (SMPTE 425) formats
SMPTE Standard
Source
Resolution
Frame Rate
Display Rate Scan Type
SMPTE 292M
SMPTE 428-9
1920 x 1080
2048 x 1080
23.976
24
25
29.970
30
47.952
48
50
59.940
60
Progressive
Y Cb Cr 4:2:2 10-Bit
8.16 ICMP(-X) HDMI 2.0 specifications
HDMI
HDMI (High-Definition Multimedia Interface) is a compact audio/video interface for transferring
uncompressed video data and compressed/uncompressed digital audio data from a HDMI-
compliant device ("the source device") to a compatible computer monitor, video projector, digital
television, or digital audio device. HDMI is a digital replacement for existing analog video standards.
HDMI 2.0 specifications
HDMI
ICMP(-X)
5: only supported in 3G level A mapping, others formats are supported in both level A and level B mapping.
