R5906790 /04 Athena 139
Image 16-2
2. Remove the rear cover from the projector.
16.3 Removal of the top cover
WARNING: Switch off the projector prior to start with this procedure, unless otherwise specified in
the procedure.
To remove the top cover from the projector the front and back covers must be first removed. This
procedure assumes that the front and back covers are already removed.
Required tools
3 mm Allen key.
How to remove the top cover?
1. Loosen the three screws at the front and the three screws at the back (reference 1, Image 16-3) using a 3 mm
Allen key.
Removal and installation of the projector covers
