R5906790 /04 Athena158
A.4 Dimensions of the Athena
Dimensions
664
559
54.5
82
689
119
232.5
160266.5
241 270
90.15
368.5
618
54.5
604.5
204
230.4
504.5
499
278.5
369
min 23
max 125
249.5
200
32.5
138.5
105.7
182
320
170
320
49
4 x M8
Image A-1: Dimensions given in millimeters.
