R5906790 /04 Athena 155
16 x AES/EBU audio channels (2 x RJ45)
8 x GPI, 8 x GPO (4 x RJ45)
2 x Gbe for content connectivity & ingest
2 x front-accessible USB 3.0 for fast ingest
2 x front-accessible USB 2.0
DCI 4K 2D up to 60fps*
DCI 4K 3D (24 or 30fps per eye)*
DCI High Frame Rates 2K 3D up to 120fps (60fps per eye)
JPEG 2000 bit-rates up to 625 Mbps
MPEG-2 (4:2:0 and 4:2:2 up to 60fps)
Input resolutions VGA up to 4K (4,096 x 2,160) @ 120Hz
Integrated storage 3.9TB effective storage (RAID-5)
via 3 x 2TB Hot-swappable 2.5" hard-drives
Control RS232, TCP/IP, 8 x GPIO
Power requirements 200-240V, 16A
Power consumption 1.1 kW
Noise level (typical at 25°C/
77°F)
dB(A) @ 1m:
48 dB(A) - Normal
Operating temperature 10 to 35 °C Max. (sea Level)
Operational humidity 20 to 80% (relative humidity)
BTU per hour 5,000 BTU/h
Airflow requirements Air Inlet (from Rear w/Feet Down): Front
Exhaust (from Rear w/Feet Down): Top (Back Through Accessories)
Exhaust airflow 140 - 180 CFM (4 - 5 m³/min)
Dimensions (WxLxH) 689 x 664 x 369 mm (excludes lens)
27.1 x 26.1 x 14.5 in. (excludes lens)
Weight 53.8 kg / 119 lbs (excludes lens)
Shipping Dimensions TBC
Shipping weight TBC
Storage temperature TBC
Storage humidity TBC
Standard accessories TBC
Certifications TBC
Warranty Limited 2 years parts and labor
Extendable up to 5 years
* Firmware upgradable
Please contact an authorized Barco representative for details
