R5906790 /04 Athena164
General Purpose In/Out
3 GPIN 3 P (reserved) 22 GPIN 3 N (reserved)
4 GPIN 4 P (reserved) 23 GPIN 4 N (reserved)
5 GPIN 5 P 24 GPIN 5 N
6 GPIN 6 P 25 GPIN 6 N
7 GPIN 7 P 26 GPIN 7 N
8 GPIN 8 P 27 GPIN 8 N
9 3D Output Reference P 28 3D Output Reference N
10 GPOUT 2 P (reserved) 29 GPOUT 2 N (reserved)
11 GPOUT 3 P (reserved) 30 GPOUT 3 N (reserved)
12 GPOUT 4 P 31 GPOUT 4 N
13 GPOUT 5 P 32 GPOUT 5 N
14 GPOUT 6 P 33 GPOUT 6 N
15 GPOUT 7 P 34 GPOUT 7 N
16 GPOUT 8 P 35 GPOUT 8 N
17 reserved 36 reserved
18 reserved 37 reserved
19 reserved
Ethernet port
10/100 Base-T – RJ45 port 1000 Base-T – RJ45 port
Pin Pair Color
Description Description
1 3 white/green TXD+ TX0+
2 3 green TXD- TX0-
3 2 white/orange RXD+ RX0+
4 1 blue – TX1+
5 1 white/blue – TX1-
6 2 orange RXD- RX0-
7 4 white/brown – Rx1+
8 4 brown – RX1-
3D interface
Pin Name Pin Name
1 +12V 9 +12V
2 Grnd 10 3D Input Reference -
3 Grnd 11 3D Display Reference +
4 RS232 RX 12 3D Display Reference -
5 RS232 TX 13 CONN_3D MODE -
6 CONN_3D_MODE + 14 CONN_SYNC -
Pin configurations
