Barco Athena User Manual

R5906790 /04 Athena166
General Purpose Output:
GPO 1-4
Definition
RJ-45 pin
EXT_GPOUT_1_P 1
EXT_GPOUT_1_N 2
EXT_GPOUT_2_P 3
EXT_GPOUT_2_N 4
EXT_GPOUT_3_P 5
EXT_GPOUT_3_N 6
EXT_GPOUT_4_P 7
EXT_GPOUT_4_N 8
GPO 5-8
Definition
RJ-45 pin
EXT_GPOUT_5_P 1
EXT_GPOUT_5_N 2
EXT_GPOUT_6_P 3
EXT_GPOUT_6_N 4
EXT_GPOUT_7_P 5
EXT_GPOUT_7_N 6
EXT_GPOUT_8_P 7
EXT_GPOUT_8_N 8
General Purpose Input:
GPI 1-4
Definition
RJ-45 pin
EXT_GPIN_1_P 1
EXT_GPIN_1_N 2
EXT_GPIN_2_P 3
EXT_GPIN_2_N 4
EXT_GPIN_3_P 5
EXT_GPIN_3_N 6
EXT_GPIN_4_P 7
EXT_GPIN_4_N 8
GPI 5-8
Definition
RJ-45 pin
EXT_GPIN_5_P 1
EXT_GPIN_5_N 2
Pin configurations
