Barco Athena User Manual

R5906790 /04 Athena54
HD-SDI settings
Source: 2K
General settings Advanced settings
Port Port type Mode Scan type Color
space
Pixel mapping Calibration
A or
B
HDSDI Single
link
4:2:2 10
bits/color
Progressive YCbCr HDSDI-Single link Single
Progressive - field
bit normal
Progressive - field
bit inverted
Progressive SF -
2nd field dominant
Progressive SF -
1st field dominant
3GSDI link 4:2:2 12
bits/color
Progressive YCbCr 3G-level A-Single
link
Single
3G-level B-Dual
link
4:4:4 10
bits/color
Progressive RGB 3G-level A-Single
link
3G-level B-Dual
link
4:4:4 12
bits/color
Progressive XYZ/
RGB
3G-level A-Single
link
3G-level B-Dual
link
A+B HDSDI Duallink
AB
4:4:4 10
bits/color
Progressive RGB HDSDI-Dual link Single
Progressive - field
bit normal
Progressive - field
bit inverted
Progressive SF -
2nd field dominant
Progressive SF- 1st
field dominant
4:4:4 12
bits/color
Progressive XYZ/
RGB
Progressive - field
bit normal
Progressive - field
bit inverted
Progressive SF-
2nd field dominant
Progressive SF- 1st
field dominant
