Barco MDNC-2221 User Manual

5. Advanced operation
4. Select one of the available input signals and confirm.
5.15 EDID timings
About EDID t imings
Following EDID timings are available for your NIO 2MP LED Display:
Refresh Rate Allows to manually select the refresh rate of the
image source video input signal depending on the
maximum refre sh rate of the display controller
connected to your display.
Preferred Orientation Allows to change the orientation of the image
source video input signal to landscape, portrait or
to let the display automatically assign the correct
orientation.
Color Depth
Allows to change the color depth to 8 or to 10 bit.
To manually set EDID timings:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source menu.
3. Enter the Timings submenu.
4. Select Refresh Rate, Preferred Orientation or Color Depth.
5. Select one of the available settings and confirm.
5.16 Display info
About display info
Your display serial number, color type, native resolution, firmware versions, etc. are available in a dedi-
cated submenu of the OSD menu.
To retrieve inf o about your display:
1. Bring up the OSD main menu.
2. Navigate to the About this Display menu to make the information visible on the screen.
5.17 Display status
About display s tatus
The Status submenu of the OSD menu provides info on the current status of your display (runtimes, tem-
peratures, etc.), the status of the connected image sources (video encoding mode, timings, etc.), the
current calibration status of your display (display function, luminance, ALC, etc.) and the status about
activated connections.
To retrieve the status of your display:
1. Bring up the OSD main menu.
2. Navigate to the Status menu.
K5903058 NIO 2MP LED DISPLAY 04/03/2014
25

Barco MDNC-2221 Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	4:3
Response time	20 ms
Display surface	Matt
Display diagonal	21.3 \
Display resolution	1600 x 1200 pixels
Display technology	LED
Viewable size diagonal	541 mm
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1400:1
Viewable size, horizontal	432 mm
Display brightness (typical)	800 cd/m²
Supported graphics resolutions	1600 x 1200 (UXGA)
On/off switch	Yes
USB hub version	2.0
DVI-D ports quantity	1
USB Type-A downstream ports quantity	3
Certification	CE0120 (MDD 93/42/EEC; A1:2007/47/EC class II b product), CE - 2004/108/EC, IEC 60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1:2005 + A1:2012, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2 No. 60601-1(2008), DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 + GB17625.1-2003, KCC pending, VCCI, FCC class B, ICES-001 Level B, FDA 510(k), RoHS
Product color	Black
Market positioning	Medical
LED indicators	Power
Panel mounting interface	100 x 100 mm
Power consumption (standby)	- W
Power consumption (typical)	36 W

Weight and Dimensions

Depth (with stand)	235 mm
Height (with stand)	572 mm
Weight (with stand)	12600 g
Depth (without stand)	84 mm
Width (without stand)	491 mm
Height (without stand)	378 mm
Weight (without stand)	- g
