Barco MDNC-2221 User Manual

7. Important information
Net weight w/o stand 7.6 kg (with glass) – 6.32 kg (without glass)
Net weight packaged with
stand
16.8 kg (with glass) – 15.52 kg (without glass)
Net weight packaged w/o stand N/A
Height adjustment range 100 mm
Tilt
-5° / +25°
Swivel -30° / +30°
Pivot
N/A
Mounting standard
VESA (100 mm)
Screen protection Protective, non-reflective glass cover (option)
Recommended modalities
CT, MR, US, DR, CR, NM , Film
Certifications CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb product),
CE - 2004/108/EC, CE - 93/42/EEC; A1:2007/47/EC class II b,
IEC 60601-1(ed.3), ANSI/AAMI ES 60601-1:2005 + C1:2009,
CAN/CSAC22.2 No. 60601-1-08:2008, DEMKO - EN 60601-1:2006,
EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 +
GB17625.1-2012, KC, VCCI, FCC class B, ICES-001 Level B , FDA
510(k), RoHS
User Guide
Quick Installation Sheet
Video cables (1 x DVI Single Link + 1 x DisplayPort)
Main cables (UK, European (CEBEC/KEMA), USA (UL/ CSA; adaptor
plug NEMA 5-15P), Chinese (CCC))
USB 2.0 cable
Supplied accessories
Adapter BRIDGEPOWER JMW190KB2400F11 (I/P: 100-240V,
50-60Hz, 2A, O/P: 24V, 3.75A):as forming part of the medical device
Optional accessories
None
QA software MediCal QAWeb
Units per pallet NA
Pallet dimensions (W x H)
NA
Warranty
5years
Operating temperature 0°C to 35°C (15°C to 30°C within specs)
Storage & transport
temperature
-20°C to 60°C
Operating humidity 8% - 80% (non-conden
sing)
Storage & transpor
t humidity
5% - 85% (non-conde
nsing)
Operation altitude
2000 m
Storage & transport altitude
7500 m
7.8 Compatible display controllers
Overview
Barco strongly recommends to use a Barco display controller with your display. All Barco display con-
trollers compatible with your display can be found in the options-tab on the product-page of your display
on w
ww.barco.com.
A user guide of the display controllers is available on the cd-rom delivered with the unit.
K5903058 NIO 2MP LED DISPLAY 04/03/2014
41

Barco MDNC-2221 Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	4:3
Response time	20 ms
Display surface	Matt
Display diagonal	21.3 \
Display resolution	1600 x 1200 pixels
Display technology	LED
Viewable size diagonal	541 mm
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1400:1
Viewable size, horizontal	432 mm
Display brightness (typical)	800 cd/m²
Supported graphics resolutions	1600 x 1200 (UXGA)
On/off switch	Yes
USB hub version	2.0
DVI-D ports quantity	1
USB Type-A downstream ports quantity	3
Certification	CE0120 (MDD 93/42/EEC; A1:2007/47/EC class II b product), CE - 2004/108/EC, IEC 60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1:2005 + A1:2012, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2 No. 60601-1(2008), DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 + GB17625.1-2003, KCC pending, VCCI, FCC class B, ICES-001 Level B, FDA 510(k), RoHS
Product color	Black
Market positioning	Medical
LED indicators	Power
Panel mounting interface	100 x 100 mm
Power consumption (standby)	- W
Power consumption (typical)	36 W

Weight and Dimensions

Depth (with stand)	235 mm
Height (with stand)	572 mm
Weight (with stand)	12600 g
Depth (without stand)	84 mm
Width (without stand)	491 mm
Height (without stand)	378 mm
Weight (without stand)	- g
