7. Important information
Power cords:
Use a power cord that matches the voltage of the power outlet, which has been approved and complies
with the safety standard of your particular country.
Do not overload wall outlets and extension cords as this may result in re or electric shock.
Mains lead protection (U.S.: Power cord): Power cords should be routed so that they are not likely to
be walked upon or pinched by items placed upon or against them, paying particular attention to cords
at plugs and receptacles.
The power supply cord should be replaced by the designated operator only at all time.
Grounding reliability
Grounding reliability can only be achieved when the equipment is connected to an equivalent receptacle
marked “Hospital Only” or “Hospital Grade”
Accessory equipment
Accessory equipment connected to the analog and digital interfaces must be in compliance with the re-
spective nationally harmonized IEC standards (i.e. IEC 60950 for data processing equipment, IEC 60065
for video equipment, IEC 61010-1 for laboratory equipment, and IEC 60601-1 for medical equipment.)
Furthermore all congurations shall comply with the system standard IEC 60601-1-1. Anyone who con-
nects additional equipment to the signal input part or signal output part is conguring a medical system,
and is therefore, responsible that the system complies with the requirements of the system standard IEC
60601-1-1. The unit is for exclusive interconnection with IEC 60601-1 certied equipment in the patient
environment and IEC 60XXX certied equipment outside of the patient environment. If in doubt, consult
the technical services department or your local representative.
Water and mo isture
Never expose the display to rain or moisture.
Never use the display near water - e.g. near a bathtub, washbasin, swimming pool, kitchen sink, laundry
tuborinawetbasement.
Ventilation
Do not cover or block any ventilation openings in the cover of the set. When installing the device in a
cupboard or another closed location, heed the necessary space between the set and the sides of the
cupboard.
Installation
Place the device on a at, solid and stable surface that can support the weight of at least 3 devices. If you
use an unstable cart or stand, the device may fall, causing serious injury to a child or adult, and serious
damage to the device.
This apparatus conforms to:
CE0120 (MDD 93/42/EEC; A1:2007/47/EC class IIb prod
uct), CE - 2004/108/EC, CE - 93/42/EEC;
A1:2007/47/EC class II b, IEC 60601-1(ed.3), ANSI/AAMI ES 60601-1:2005 + C1:2009, CAN/CSAC22.2
No. 60601-1-08:2008, DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, CCC - GB9254-2008 +
GB4943.1-2011 + GB17625.1-2012, KC, VCCI, FCC class B, ICES-001 Level B, FDA 510(k), RoHS
National Scandinavian Deviations for CL. 1.7.2:
Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan"
Norway: "Apparatet tilkoples jordet stikkontakt"
Sweden: "Apparaten skall anslutas till jordat uttag"
30
K5903058 NIO 2MP LED DISPLAY 04/03/2014
