Barco MDNC-2221 User Manual

1. Welcome!
1. WELCOME!
1.1 About t he product
Overview
Thank you for choosing this NIO 2MP LED Display!
NIO 2MP LED Display is an industry-standard 2MP color display system with LED backlights for depen
d-
able diagnostic viewing in high-bright color. NIO 2MP LED Display provides an effective display solution
for a multitude of applications and modalities.
Confident color reading
Equipped with high-bright LED backlights, NIO 2MP LED Display delivers excellent brightness and more
shades of gray to detect subtle details more quickly. The unique front sensor ensures you see co
nsistent
and precise images at all times for confident diagnoses.
On-demand image quality checks
As the front sensor works seamlessly together with Barco’s online MediCal QAW eb service for automated
Quality Assurance and calibration, NIO 2MP LED Display makes sure you are viewing perfect DICOM
images — at the click of a button — without interrupting your workflow.
A good investment
Using power-efficient LED backlights, NIO 2MP LED Display is as low in power consumption as it is high
in brightness. Because it uses less power, the display produces less heat and requires less c ooling, which
impacts maintenance and operational costs. Additionally, the LED backlights offer a long lifetime — even
at high brightness — providing a high return on your investment.
CAUTION: Read all the important safety information before installing and operating your
NIO 2MP LED Display. Please refer to the dedicated chapter in this user guide.
1.2 What’s in the box
Overview
Your NIO 2MP LED Display comes with:
• the display
• a system tilt and swivel foot
• thisNIO2MPLEDDisplayuserguide
• a system CD
• a DisplayPort cable
•aDVIcable
•anUSBcable
•anACpowercord
• an external power supply
If you ordered a Barco display controller, it’s also in the box together with its accessories. A dedicated
user guide is available on the system CD.
K5903058 NIO 2MP LED DISPLAY 04/03/2014
3

Barco MDNC-2221 Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	4:3
Response time	20 ms
Display surface	Matt
Display diagonal	21.3 \
Display resolution	1600 x 1200 pixels
Display technology	LED
Viewable size diagonal	541 mm
Viewable size, vertical	324 mm
Contrast ratio (dynamic)	-
Contrast ratio (typical)	1400:1
Viewable size, horizontal	432 mm
Display brightness (typical)	800 cd/m²
Supported graphics resolutions	1600 x 1200 (UXGA)
On/off switch	Yes
USB hub version	2.0
DVI-D ports quantity	1
USB Type-A downstream ports quantity	3
Certification	CE0120 (MDD 93/42/EEC; A1:2007/47/EC class II b product), CE - 2004/108/EC, IEC 60950-1:2005 + A1:2009 (2ND EDITION), IEC 60601-1:2005 + A1:2012, ANSI/AAMI ES 60601-1:2005 + C1:2009 + A1:2012, CAN/CSAC22.2 No. 60601-1(2008), DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, CCC - GB9254-2008 + GB4943.1-2011 + GB17625.1-2003, KCC pending, VCCI, FCC class B, ICES-001 Level B, FDA 510(k), RoHS
Product color	Black
Market positioning	Medical
LED indicators	Power
Panel mounting interface	100 x 100 mm
Power consumption (standby)	- W
Power consumption (typical)	36 W

Weight and Dimensions

Depth (with stand)	235 mm
Height (with stand)	572 mm
Weight (with stand)	12600 g
Depth (without stand)	84 mm
Width (without stand)	491 mm
Height (without stand)	378 mm
Weight (without stand)	- g
