Page #30 background imageLoading...
Page #30 background image
5. Advanced operation
Black luminance: Shows the measured backlight luminance.
DICOM Calibration Status:
No calibration executed yet: No other information is visible
Calibration executed: When the calibration is executed, the following extra information is shown:
Backlight runtime elapsed since latest calibration, display function, ambient light compensation, read-
ing room.
Current DICOM Settings
Display Function: Shows the current display function.
Ambient Light Compensation: Shows the ambient light compensation status.
Reading room: Shows the selected reading room.
To retrieve the DICOM status report:
1. Bring up the OSD main menu.
2. Navigate to the Conguration > Calibration > Embedded QA menu.
3. Select DICOM status report to make the information visible on the screen.
5.14.3 DICOM compliance check
About D ICOM compliance check
The DICOM compliance check will measure the DICOM curve of your display in different steps. After
measurement, the DICOM status report is shown.
To start DICOM compliance check:
1. Bring up the OSD main menu.
2. Navigate to the Conguration > Calibration > Embedded QA menu.
3. Select DICOM compliance check to start t he compliance check.
Warning:Pressing a key during the compliance check will abort the check.
5.14.4 DICOM calibration
About DICOM c alibration
TheDICOMcalibrationwilladdacorrectiontothecurrentDICOMcurvetoapproachtheperfectDICOM
curve as good as possible.
To start DICOM calibration:
1. Bring up the OSD main menu.
2. Navigate to the Conguration > Calibration > Embedded QA menu.
3. Select DICOM cal ibration to start the calibration.
Warning:Pressing a key during calibration will abort the calibration, previous values will be restored.
Note: After calibration, the compliance check will start automatically.
5.14.5 Reset DICOM calibration
About reset DICOM calibration
It is possible to restore the original (not corrected) DICOM curve.
To reset the DICOM calibration:
1. Bring up the OSD main menu.
2. Navigate to the Conguration > Calibration > Embedded QA menu.
28
K5902114 NIO 3MP LED DISPLAY 03/10/2016
