5. Advanced operation
5.17 EDID timings
About EDID t imings
Following EDID timings are available for your Nio 3MP LED Display:
• Refresh Rate: Allows to manually select the refresh rate of the image source video input signal de-
pending on the maximum refresh rate of the display controller connected to your display.
• Color Depth: Allows to change the color depth to 8 or to 10 bit.
Please note that the Color Depth setting is only available for the DisplayPort input.
To manually set EDID timings:
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source > Input Settings > DisplayPort or DVI menu.
3. Enter the EDID submenu.
4. Select Refresh Rate or Color Depth.
5. Select one of the available settings and confirm.
5.18 EDID format
About EDID format
Your Nio 3MP LED Display describes its capabilities to the display controller by me
ans of display identifi-
cation data. This data contains timings, display size, pixel mapping info, etc. and is needed to make sure
that the video source can be correctly displayed.
Display identification data is structured in a standard VESA format. Depending on the configuration setup
of your system, a different format can be used.
The Nio 3MP LED Display supports following EDID formats:
• E-EDID V1.4: E-EDID is a mature and more commonly used format. It is supported by most display
controllers and operating systems.
• DisplayID V1.3: DisplayID is designed to replace E-EDID and suppor
ts more advanced communi-
cation between your Nio 3MP LED Display and its display controller. Since not all display controllers
and operating systems support DisplayID already, it should only be selected if all components are
DisplayID compatible.
To select the EDID format
1. Bring up the OSD main menu.
2. Navigate to the Configuration > Image Source > Input Settings menu.
3. Enter the EDID format submenu.
4. Select one of the available settings and confirm.
5.19 Display in fo
About display info
Your display serial number, color type, native resolution, firmware versions, etc. are available in a dedi-
cated submenu of the OSD menu.
30
K5902114 NIO 3MP LED DISPLAY 03/10/2016
