2.2 Rear view
Overview
1
2
3
4
Image 2–2
1. VESA mount screw holes (100 x 100 mm, 200 x 100 mm)
2. Cable routing channel
3. Cable routing channel expansion clip
4. Connector compartment cover
2.3 Connector view
Overview
1 3 4 5 6 7 8 2 9
Image 2–3
1. 24 VDC power in
2. Power switch
3. DVI-D out
4. SDI in
5. DVI-D 1 in
6. DVI-D 2 in
7. HDMI 2.0 in
8. DisplayPort 1.2 in
9. RS-232C
