53K5902149 /02 MDSC-8331
Dimensions power supply
(W x H x D)
209 x 64 x 42 mm (8,2" x 2,5" x 1,6")
Dimensions packaged (W x
H x D)
980 x 630 x 200 mm (38,6" x 24,8" x 7,9")
Net weight display 11.8 kg (26 lbs)
Net weight power supply 0.9 kg (1.98 lbs)
Net weight packaged 17.5 kg (38.6 lbs)
Power supply DC output
cable length
1.5 m (5 ft)
Mounting standard VESA (100 x 100 mm, 200 x 100 mm)
Screen protection 2-side, anti-reflective, alkali-aluminosilicate glass
Recommended modalities Endoscopy, Laparoscopy, PACS
Certifications CE (Medical Device Class I)
ANSI/AAMI ES 60601-1:2005/(R)2012 and A1:2012, C1:2009/(R)2012
and A2:2010/(R)2012 - Med. El. Equip., Part 1: general req. for basic
safety and essential performance
CAN/CSA-C22.2 No. 60601-1: 14 Medical Electrical Equipment - Part 1:
General Requirements for Basic Safety and Essential Performance
(Harmonized with Ed. 3.1)
IEC 60601-1: 2012 Edition 3.1 (Medical electrical equipment – Part 1:
General requirements for basic safety and essential performance)
EN 60601-1: 2006 + A1:2013 (Medical electrical equipment - Part 1:
General requirements for safety)
Electromagnetic Compatibility: FMC Medical EMC Standards: IEC60601-
1-2: 2, FCC CFR47 part 15/Class B
Approvals/Marking: CE, c-UL-us
ROHS-2, REACH, WEEE compliant
Supplied accessories 1x printed User Guide (English)
1x documentation disc, containing all translations of the User Guide
1x external power supply
Mains cables
Optional accessories Power extension cable 1.5m (5 ft) (order p/n C-47D2001P50MF)
Power extension cable 4.6m (15 ft) (order p/n C-47D2004P57MF)
Warranty 3 years
Operating temperature 10 ~ 40°C
Storage temperature -18 ~ +60°C
Operating humidity 25 ~ 75% (non-condensing)
Storage humidity 15 ~ 90% (non-condensing)
Operating altitude 3000 m max
Storage atmospheric
pressure
70 ~ 110 kPa
Important information
