R5900049 /07 ClickShare CSE-80034
2.6 Ports used by the ClickShare Base Unit
Overview
Sender CSE-800 Base Unit
ClickShare Button TCP 6541; 6542; 6543; 6544; 6545
UDP 514
ClickShare App TCP 6541; 6542; 6543; 6544; 6545
UDP 5353
ClickShare
Configurator
TCP 80; 443
ClickShare REST
API & CMGS
TCP
UDP
4000; 4001
Airplay TCP 4100-4200; 7000; 7100; 47000
UDP 4100-4200; 5353
Google Cast TCP 8008; 8009; 9080
UDP 1900; 32768:61000
3
MirrorOp for
ClickShare
TCP 6541-6545
UDP 5353
Auto-update TCP 80; 443
Button Manager TCP 6546
If Proxy settings are enabled in the Configurator for auto-update functionality, additional ports may be used.
CSE-800 Specifications
3: Google Cast will pick a random UDP port above 32768 to facilitate video streaming
