4.1 Installation methods for the Base unit
For optimal performance, install the Base Unit close to the display and avoid obstacles between the
Base Unit and the Buttons. Do not block the fan inlets and outlets of the Base Unit!
Introduction to the installation methods
The base unit can be installed in different ways in a meeting room:
• Table mounted
• Wall mounted
• Ceiling mounted
• Rack mounted
The antennas are removable. They can be fixed to the Base Unit depending on the way the Base Unit is
installed in the room. The antennas can rotate for better wireless connection.
Using extension cables for the antennas is allowed, but this can reduce the performance.
4.2 Table mounting
Overview
Put the Base Unit directly on the meeting room table.
The total weight of the Base Unit is 2.2 kg.
4.3 Wall mounting
About wall mounting
Use the mounting brackets, inserted in the CSE-800 box, to mount the Base unit on the wall.
Required tools
• a drill (type of drill depends on the type of wall)
• Torx T10 screwdriver
• Additional screwdriver that matches the mounting screws (mounting screws not delivered)
Required parts
• 2 mounting screws
• 2 plugs
• 2 Mounting brackets with fixation screws (included in the CSE-800 box)
How to install
1. Mount both brackets to the Base unit as shown. Use for each 4 screws.
