Barco RLM W12 Service Manual

126 of 123
1080P59
3G Level A
SMPTE 424M 3Gbps
YCbCr
4:2:2
10
1080P60
3G Level A
SMPTE 424M 3Gbps
YCbCr
4:2:2
10
1080P50
3G Level B
SMPTE 424M 3Gbps
YCbCr
4:2:2
10
1080P59
3G Level B
SMPTE 424M 3Gbps
YCbCr
4:2:2
10
1080P60
3G Level B
SMPTE 424M 3Gbps
YCbCr
4:2:2
10
High Definition TV (HDTV) support
The projector shall be capable of displaying the following HDTV display modes via either
the digital DVI connectors.
640 x 480, progressive (60p), up to 60Hz. (SMPTE 293M-1996)
1280 x 720, progressive (60p), up to 60Hz. (SMPTE 296M-1997)
1920 x 1080, interlaced (30i), up to 60Hz. (SMPTE 274M-1998)
720 x 576 , progressive (50p),up to 50Hz.(HDTV ATV7250)
1920 x 1080, interlaced (60p), up to 60Hz. (SMPTE 274M-1998)
Video Timing Mode :
NTSC : Hsync 15734Hz +- 10Hz Vsync 59.94 Hz +- 1Hz
PAL : Hsync 15625Hz +- 10HZ Vsync 50Hz +-1Hz
PAL-M : Hsync 15734Hz +- 10Hz Vsync 59.94 Hz +- 1Hz
NTSC M : Hsync 15625Hz +- 10HZ Vsync 60Hz +-1Hz
SECAM : Hsync 15625Hz +- 10Hz Vsync 50Hz +-1Hz
480i : Hsync 15734Hz +- 10HZ Vsync 59.9Hz +- 1Hz
576i : Hsync 15625Hz +-10Hz Vsync 50Hz +-1Hz
Detail of timing chart
Timing name
Freq.
H(KHz)
Freq.
V(Hz)
Clock
(M Hz)
H period
H display
H Sync
H backp
V Total
V display
V Sync
V backp
640*480-60
31.47
59.93
25.175
800
640
96
40
525
480
2
25
800*600-60
37.88
60.32
40
1056
800
128
88
628
600
4
23
848*480-47.95
23.674
47.95
25
1056
848
80
104
497
480
5
9
848*480-59.94
29.83
59.94
31.5
1056
848
80
104
500
480
5
12

Barco RLM W12 Specifications

General

Matrix size	0.96 \
Heat dissipation	3412 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	1600:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Focal length range	- mm
Lamp power	400 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Full HD	Yes
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
CardBus PCMCIA slot type	No
Ethernet LAN data rates	10, 100 Mbit/s
Optical disc player type	Not included
Noise level	43 dB
Certification	FCC part 15 Class A, CE EN55022 Class A, CE, TUV, WEEE
Dot clock scanning frequency	165 MHz
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1000 W
Power consumption (standby)	2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR

Weight and Dimensions

Depth	631 mm
Width	500 mm
Height	270 mm
Weight	32000 g
Package depth	830 mm
Package width	669 mm
Package height	448 mm
