Barco RLM W12 Service Manual

127 of 123
1024*768-60
48.36
60
65
1344
1024
136
160
806
768
6
29
1024-768-85
68.88
85.03
94.5
1376
1024
96
208
808
768
3
36
1280*720-47.95
35.531
47.95
57.987
1632
1280
128
176
741
720
3
17
1280*768-60
47.776
59.870
79.5
1664
1280
128
192
798
768
7
20
1280*800-60
49.702
59.810
83.500
1680
1280
128
200
831
800
6
22
1280*960-60
60
60
108
1800
1280
112
312
1000
960
3
36
1280*1024-60
63.98
60.02
108
1688
1280
112
248
1066
1024
3
38
1366*768-60
47.712
59.790
85.5
1792
1366
143
213
798
768
3
24
1440*900-60
55.935
59.887
106.5
1904
1440
152
232
934
900
6
25
1600*1200-60
75
60
162
2160
1600
192
304
1250
1200
3
46
1920*1080-47.95
53.225
47.95
135.403
2544
1920
200
312
1110
1080
3
26
1680*1050-59.94
65.179
59.94
146
2240
1680
176
280
1089
1050
6
30
640*480-66
35
66.67
30.24
864
640
64
96
525
480
3
39
832*624-74.5
49.72
74.55
57.28
1152
832
64
224
667
624
3
39
NTSC ( M)
15.734
59.94
13.5
─
─
─
─
─
─
─
─
NTSC ( 4.43 )
15.734
59.94
13.5
─
─
─
─
─
─
─
─
PAL ( B,G,H,I)
15.625
50
13.5
─
─
─
─
─
─
─
─
PAL ( N )
15.625
50
13.5
─
─
─
─
─
─
─
─
PAL ( M )
15.734
60
13.5
─
─
─
─
─
─
─
─
SECAM ( M )
15.625
50
13.5
─
─
─
─
─
─
─
─
RGBS
50
1440x480i
15.73
60
27
1716
1440
124
114
262
240
3
16
480i
15.734
59.94
13.5
858
712
63
63
262
242
3
14
1440x576i
15.62
50
27
1728
1440
126
138
312
288
3
20
576i
15.625
50
13.5
864
702
63
79
312
287
2.5
20
480p
31.47
59.94
27
858
720
62
60
525
480
6
30
576p
31.25
50
27
864
720
64
68
625
576
5
39
1920X1200RB
74.04
59.95
154
2080
1920
32
80
1235
1200
6
26
1920X1200
61.816
49.93
158.25
2560
1920
200
320
1238
1200
6
29
1400X1050
65.517
59.98
121.75
1864
1400
144
232
1089
1050
4
32
1035i
33.75
60
74.25
2200
1920
44
148
562
517
5
35
1080i
28.13
50
74.25
2640
1920
44
148
562
540
5
15
1080i (Aus )
31.25
50
72
2304
1920
168
184
625
540
5
57
1080i
33.75
59.94
74.176
2200
1920
44
148
562
540
5
15
1080i
33.75
60
74.25
2200
1920
44
148
562
540
5
15

Barco RLM W12 Specifications

General

Matrix size	0.96 \
Heat dissipation	3412 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	1600:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Focal length range	- mm
Lamp power	400 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Full HD	Yes
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
CardBus PCMCIA slot type	No
Ethernet LAN data rates	10, 100 Mbit/s
Optical disc player type	Not included
Noise level	43 dB
Certification	FCC part 15 Class A, CE EN55022 Class A, CE, TUV, WEEE
Dot clock scanning frequency	165 MHz
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1000 W
Power consumption (standby)	2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR

Weight and Dimensions

Depth	631 mm
Width	500 mm
Height	270 mm
Weight	32000 g
Package depth	830 mm
Package width	669 mm
Package height	448 mm
