Barco RLM W12 Service Manual

31 of 123
Table3: Error code definition (continued)
Error code
Definition
Error code
Definition
44
ErrMsgFan16RotateError
45
ErrMsgFan17RotateErro
46
ErrMsgFan18RotateError
47
ErrMsgFan19RotateError
48
ErrMsgFan20RotateError
49
ErrMsgFan21RotateError
50
ErrMsgFan22RotateError
51
ErrMsgFan23RotateError
Error Code Message – Troubleshooting and what parts need to replace
0
ErrMsgOverTempInlet: –Temp. is over spec. Check if there is anything
blocks in inlet or replace Inlet thermal sensor.
1
ErrMsgOverTempDMD – Temp. is over spec. Check or replace DMD thermal
sensor.
2
ErrMsgOverTempLamp1– Check or replace Lamp 1 thermal sensor state.
3
ErrMsgOverTempLamp2– Check or replace Lamp 2 thermal sensor state.
4
ErrMsgOverTempBallast1–Check and replace Ballast1 thermal state.
5
ErrMsgOverTempBallast2 –Check and replace Ballast2 thermal state.
6
ErrMsgFanInitError–Anyone fan could be error when power on. Thus, check
and replace error fan you find out. And, try to replace fan board.
7
ErrMsgFan0RotateError – Fan0 gets error during projector working. Check
and replace fan 0.
8
ErrMsgFan1RotateError – Fan1 gets error during projector working. Check
and replace fan 1.
9
ErrMsgFan2RotateError – Fan2 gets error during projector working. Check
and replace fan 2.
10
ErrMsgFan3RotateError – Fan3 gets error during projector working. Check
and replace fan 3.
11
ErrMsgFan4RotateError – Fan4 gets error during projector working. Check
and replace fan 4.
12
ErrMsgFan5RotateError – Fan5 gets error during projector working. Check

Barco RLM W12 Specifications

General

Matrix size	0.96 \
Heat dissipation	3412 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	1600:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Focal length range	- mm
Lamp power	400 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Full HD	Yes
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
CardBus PCMCIA slot type	No
Ethernet LAN data rates	10, 100 Mbit/s
Optical disc player type	Not included
Noise level	43 dB
Certification	FCC part 15 Class A, CE EN55022 Class A, CE, TUV, WEEE
Dot clock scanning frequency	165 MHz
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1000 W
Power consumption (standby)	2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR

Weight and Dimensions

Depth	631 mm
Width	500 mm
Height	270 mm
Weight	32000 g
Package depth	830 mm
Package width	669 mm
Package height	448 mm
