Barco RLM W12 Service Manual

32 of 123
and replace fan 5.
13
ErrMsgFan6RotateError – Fan6 gets error during projector working. Check
and replace fan 6.
14
ErrMsgFan7RotateError –Fan7 gets error during projector working. Check and
replace fan 7.
15
ErrMsgDMDInitFail –Check and replace DMD board and DMD chip.
16
ErrMsgLampInitFail –Check and replace ballast 1.
17
ErrMsgLampLitFail –Check and replace Lamp 1.
18
ErrMsgBallastUartError –Check and replace ballast 1 and power board.
19
ErrMsgExGpioFail –Check and replace video or main formatter board.
20
ErrMsgInterLockOpen–Check and confirm Interlock.
21
ErrMsgGF9450NoResponse –Check and replace video board.
22
ErrMsgSystemI2cFail –Check and replace all board.
23
ErrMsgSoftwareI2cFail –Reserved & None for this model.
24
ErrMsgEepromFail –Check and replace main formatter board.
25
ErrMsgEdidFail–Check and replace video board.
26
ErrMsgEepVersionFail–Reserved & None for this model.
27
ErrMsgRstGennum –Reserved & None for this model.
28
ErrMsgFan8RotateError –Fan8 gets error during projector working. Check and
replace fan 8.
29
ErrMsgFan9RotateError –Fan9 gets error during projector working. Check and
replace fan 9.
30
ErrMsgFan10RotateError –Fan10 gets error during projector working. Check
and replace fan 10.
31
ErrMsgFan11RotateError –Fan11 gets error during projector working. Check
and replace fan 11.
32
ErrMsgLamp2LitFail ––Check and replace Lamp 2.
33
ErrMsgBallast2UartError ––Check and replace ballast 2 and power board.
34
ErrMsgGtInletTp ––Reserved & None for this model.
35
ErrMsgGtDmdTp –Reserved & None for this model.
36
ErrMsgInletTempSensorFail––Reserved & None for this model.
37
ErrMsgDMDTempSensorFail –Reserved & None for this model.
38
ErrMsgGeoSystemFail – Check and replace the W2 board.
39
ErrMsgNormal ––It represent everything is normal.
40
ErrMsgFan12RotateError –– Reserved & None for this model.
41
ErrMsgFan13RotateError –– Reserved & None for this model.
42
ErrMsgFan14RotateError –– Reserved & None for this model.

Barco RLM W12 Specifications

General

Matrix size	0.96 \
Heat dissipation	3412 BTU/h
Native aspect ratio	16:10
Projection distance	- m
Projection technology	DLP
Contrast ratio (typical)	1600:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Focal length range	- mm
Lamp power	400 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	1500 h
Service life of light source (economic mode)	2000 h
Full HD	Yes
Analog signal format system	NTSC
Supported graphics resolutions	1600 x 1200 (UXGA), 1920 x 1200 (WUXGA)
BNC input ports	5
Serial interface type	RS-232
USB 2.0 ports quantity	0
CardBus PCMCIA slot type	No
Ethernet LAN data rates	10, 100 Mbit/s
Optical disc player type	Not included
Noise level	43 dB
Certification	FCC part 15 Class A, CE EN55022 Class A, CE, TUV, WEEE
Dot clock scanning frequency	165 MHz
Placement	Desktop, Ceiling
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Power source	AC
AC input voltage	90 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1000 W
Power consumption (standby)	2 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Sustainability certificates	RoHS
Remote control type	IR

Weight and Dimensions

Depth	631 mm
Width	500 mm
Height	270 mm
Weight	32000 g
Package depth	830 mm
Package width	669 mm
Package height	448 mm
