• Layout mode: Standard layout (1x1 layout)
• Video Timing: 2560 x 1600 (WQXGA) @120 Hz
• Color depth: 30 bpp
• Connector: DisplayPort 1.2 or HDMI
Connecting with the quad DP 1.2 Input card
You can use one of the following methods. The resulting image will always be an Active Stereo image.
Source
Layout mode
Video Timing /
cable
Fixed
configuration?
Color depth
Active Stereo
(sequential L/R)
Standard layout
(1x1 layout)
2560 x 1600 @120
Hz
30 bpp
Active Stereo
(sequential L/R)
4 Column mode
(4x1 layout)
960 x 2160 @120
Hz
30 bpp
Active Stereo
(sequential L/R)
4 Quadrant mode
(2x2 layout)
1920 x 1080 @120
Hz
30 bpp
Passive Stereo
(separate L/R)
Standard layout
(1x1 layout)
3840 x 2160 @60
Hz
• Cable 1: left eye
• Cable 2: right
eye
30 bpp
Passive Stereo
(dual pipe L/R)
2 Column mode
(2x1 layout)
1920 x 2160 @60
Hz
• Cable 1: left eye,
left column
• Cable 2: left eye,
right column
• Cable 3: right
eye, left column
• Cable 4: right
eye, right
column
30 bpp
8.14.4 3D Setup
Why change the 3D setup?
While Barco can provide a 3D emitter and active shutter glasses as options to this projector, you are also free
to use a 3D emitter and active shutter glasses of your own choice. Since glasses and emitter can have various
specifications compared to the ones Barco can provide, the 3D setup menu allows you to configure the output
image to the specifications of your glasses and emitter. The following can be configured:
• Swap Eyes: You can choose to invert the stereo Sync output signal ( depending on the chosen 3D emitter
and glasses).
• Swap frame pair: This setting allows you to correct the frame doubling sequence. If the frame rate of the
projected moving 3D content doesn’t look smooth, this option may help improve this.
• Dark time: You can select how much dark time the projected image will have between frames. You can
choose one of the options between 1000 µs and 2500 µs.
• Output mode: Choose the desired output mode. For more details, see further.
• Sync Delay: You can increase or decrease the sync delay. The scale goes from –10 000 µs to +10 000 µs
with a step of 100 µs.
Choosing the desired output mode
The following output modes are available:
• AutoStereo: Automatic mode (2D input = 2D output, 3D input = Active Stereo output).
• Mono: Forces all source signals to 2D output.
• ActiveStereo: Forces all source signals to Active Stereoscopic 3D.
Use the following table as an indicator of what display mode you require.
