191R5906112 /15 UDX
3D Active eye wear (optional), passive circular (optional); 2 flash up to 200Hz*
Inputs Single HDBaseT; HDMI2.0 (HDCP2.2, HDR10); DP 1.2 (HDCP 1.3); Quad
3G/12G SDI / BarcoLink ULTRA
Optional Inputs Quad DP1.2 / Fiber SFP
Input resolutions From NTSC up to 4K (4,096 x 2,160)
refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 MHz
Software tools Projector Toolset + Android app + iOS app
Control XLR wired + IR, RS232, Wifi (opt), GSM (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi (opt)
Power requirements 120-160 V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz
Max. power consumption 3750W
Noise level (typical at 25°C/
77°F)
58dB(A)
Operational ambient
temperature
0-40°C / 32°-104°F (reduce power >40°C)
Operational humidity 0-80% (non condens)
Dissipation BTU 12,795
Dimensions (WxLxH) 660 x 830 x 350 mm / 25.98 x 32.67 x 13.77 inches
Shipping Dimensions (WxLxH) 800 x 1,200 x 685 mm / 31.49 x 47.24 x 26.96 inches
Weight 92kg (202 lbs)/shipping weight from factory: 110kg (242 lbs)
Standard accessories Power cord, wireless/XLR wired rugged remote control
Certifications Compliant with UL60950-1 and EN60950-1 complies with FCC rules &
regulations, part 15 Class A and CE EN55032 Class A, Rohs
Warranty 3 years
A.11 Specifications of the UDX-U32
Specifications
Projector type UXGA 3-chip DLP digital projector
Technology 0.96" DMD™ x3
Resolution 1,600 x 1,200
Brightness 30,000 center lumens / 29,000 ansi lumen / 32,000 ISO
Contrast ratio Full field 2200:1 / Barco Dyna Black 20000:1
Brightness uniformity 95%
Aspect ratio 4:3
