195R5906112 /15 UDX
HDBase T specifications
Specification Value
Pixel rate 25 297 MHz pixel clock
Color space
YCbCr 4:2:2
YCbCr 4:4:4
RGB 4:4:4
Color depth
24 bpp
30 bpp
36 bpp
HDCP support HDCP 1.x supported on HDBaseT Input 1
Network support Yes, on HDBaseT Input 1
For future release
3D support
Interlaced support
Not supported
Audio
Power over HDBaseT
Video timings
progressive
7
Layout mode Supported formats
Standard layout (1x1
layout)
Up to 4096 x 2160 @24 Hz
Up to 4096 x 2160 @25 Hz
Up to 4096 x 2160 @30 Hz
Up to 2048 x 1080 @48 Hz
Up to 2560 x 1600 @50 Hz
Up to 2560 x 1600 @60 Hz
2 Column mode (2x1
layout)
1920 x 2160 @50 Hz
1920 x 2160 @60 Hz
2048 x 2160 @50 Hz
2048 x 2400 @60 Hz
Native video timings
UDX-U-series: 1600 x 1200 @60 Hz
UDX-W-series: 1920 x 1200 @60 Hz
UDX-4k-series: 3840 x 2160 @60 Hz
CAUTION: The HDBaseT inputs can bridge a distance of 100 m but are sensitive to radiated
electromagnetic interference: radiated electromagnetic interference (e.g. from GSM or switching
inductive or capacitive loads) within the limits of electromagnetic compatibility requirements of 3 V/
m can cause random flashes or temporary loss of the projected image.
As such, shielded CAT-6 cables with metal RJ-45 connectors are recommended; choose cable
length no longer than required and route HDBT cable optimally screened from possible sources of
electromagnetic emission.
A.15 Specifications DisplayPort 1.2 inputs
For readability, the video timings listed are summarized. For the full list of video timings, refer to the
appendices.
DisplayPort 1.2 specifications
Pixel rate Up to 600 MHz pixel clock
Color space
YCbCr 4:2:2
YCbCr 4:4:4
RGB 4:4:4
