R5906112 /15 UDX196
Color depth
• 24 bpp
• 30 bpp
• 36 bpp
Data rate support
• 1.62 Gbps: Reduced Bit Rate (RBR)
• 2.7 Gbps: High Bit Rate (HBR)
• 5.4 Gbps: High Bit Rate 2 (HBR2)
For future release
• Interlaced support
• HDCP 1.4
Audio not supported
3D support
• Field sequential 3D (Active 3D)
• Passive stereoscopic 3D (Passive stereo) converted to active 3D
Video timings
progressive
9
2D / 3D Layout Mode
10
Supported formats
2D Standard layout (1x1
layout)
• Up to 4096 x 2160 @24 Hz
• Up to 4096 x 2160 @30 Hz
• Up to 2048 x 1080 @48 Hz
• Up to 4096 x 2160 @50 Hz
• Up to 4096 x 2160 @60 Hz
• Up to 2560 x 1600 @120 Hz
2D 2 column mode (2x1
layout)
• 1920 x 2160 @60 Hz
• 1920 x 2160 @120 Hz
• 1920 x 2400 @60 Hz
• 2048 x 2160 @60 Hz
• 2048 x 2160 @120 Hz
2D 4 quadrant mode (2x2
layout)
• 960 x 1080 @120 Hz
• 960 x 1200 @120 Hz
• 1280 x 1080 @60 Hz
• 1280 x 1080 @120 Hz
• 1280 x 1600 @60 Hz
• 1280 x 1600 @120 Hz
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
2D 4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @60 Hz
Active 3D Standard layout (1x1
layout)
• 1600 x 1200 @120 Hz
• 2560 x 1080 @120 Hz
• 2560 x 1600 @120 Hz
Active 3D 2 column mode (2x1
layout)
1920 x 2160 @120 Hz
Active 3D 4 quadrant mode (2x2
layout)
• 1920 x 1080 @120 Hz
• 1920 x 1200 @120 Hz
• 2048 x 1080 @120 Hz
Active 3D 4 column mode (4x1
layout)
• 960 x 2160 @120 Hz
• 960 x 2400 @120 Hz
• 1024 x 2160 @120 Hz
Passive
stereo
Standard layout (1x1
layout)
3840 x 2160 @60 Hz
Specifications
9. For the full list of video timings, see Appendix
10. Only 1x1 layout is supported on the Quad Combo input Mk1 and Mk2. The Quad DP1.2 input supports all layout configurations.
