R5906112 /15 UDX118
9.1 Saving the current projector settings in a
profile
Which settings can be saved to a profile?
Profile domain
name
Settings saved
Illumination
• Illumination power for each source
• Light sensor enabled / disabled
• Light sensor set point
Source Active source selection & EDID
• Contrast
• Brightness
• Saturation
• Sharpness
• Gamma
• Used gamma type
• Digital zoom (width / height / factor + enabled/disabled)
• Digital shift (x / y + enabled / disabled)
• Output resolution
Display (3D
settings)
• 3D Display mode used
• Swap eyes on / off
• Swap frame pair on / off
• Dark time and sync delay values
Realcolor
TM
• Brilliant Color mode (if available)
• P7 desired values
• P7 measured values
Warp
• Warp status enabled / disabled
• Screen size
• Warp file selected (if available)
• Transport delay
Note: Bow and 4 corners warp cannot be saved.
Blend
• Blend mask enabled / disabled
• All Masks (top / bottom / left / right) and heights (top / bottom / left / right)
• Blend files enabled / disabled (if available)
• Blend file selected (if available)
Black level
• Black level file enabled / disabled
• Black Level file selected (if available)
• Basic black level enabled / disabled
• Black level settings (top / bottom / left / right)
• RGB gain values (Red, Green and Blue values)
PQ (HDR)
• Screen luminance (unit and value)
• HDR Boost value
• DynaBlack mode
Installation
• Lens parameters (lens zoom, focus, shift and iris (if available))
3
• Orientation (mounting & projection)
• Scaling mode
• Position of motorized frame (if used).
• Shutter status (open or closed).
Cooling
4
Selected Cooling mode
GUI – Projector profiles
3. only valid if recalled with same lens
4. Only if external cooler is installed
