189R5906112 /15 UDX
Lenses TLD+ 0.37, 0.65-0.85, 0.8-1.16:1 ; 1.25-1.6:1 ; 1.5-2.0:1 ; 2.0-2.8:1 ; 2.8-
4.5:1 ; 4.5-7.5:1 ; 7.5-11.5:1
Optical lens shift Vertical between -100% to +130%, depending on lens
Horizontal up to +/- 40%, depending on lens
Motorized zoom and focus (with lens memory on TLD lenses)
Motorized lens shift (with position memory on all lenses)
Color correction P7
Light source laser phosphor with inorganic phosphor wheel
Light source lifetime 20,000 hrs
Optical dowser Digital
Picture-by-picture Two sources simultaneously
Orientation 360°
Sealed DLP™ core standard
DMX 512 standard
WARP Direct adjust OSD + toolset
Image processing Embedded warp & blend
Keystone correction Yes
Integrated web server Yes
CLO (constant light output) Standard
3D Active eye wear (optional), passive circular (optional); 2 flash up to 200Hz*
Inputs Single HDBaseT; HDMI2.0 (HDCP2.2, HDR10); DP 1.2 (HDCP 1.3); Quad
3G/12G SDI / BarcoLink ULTRA
Optional Inputs Quad DP1.2 / Fiber SFP
Input resolutions From NTSC up to 4K (4,096 x 2,160)
refresh rates:
24hz to 120hz 4K/4KUHD (4096 x 2160/ 3860 x 2400) to 240hz WQXGA
(2560 x 1600)
Max. pixel clock 600 MHz
Software tools Projector Toolset + Android app + iOS app
Control XLR wired + IR, RS232, Wifi (opt), GSM (opt)
Network connection 10/100 base-T, RJ-45 connection, Wifi (optional)
Power requirements 120-160 V (reduced power) / 200-240V (+/- 10%), 20A, 50-60Hz
Max. power consumption 3750W
Noise level (typical at 25°C/
77°F)
58dB(A)
Operational ambient
temperature
0-40°C / 32°-104°F (reduce power >35°C)
Operational humidity 0-80% (non condens)
Dissipation BTU 12,795
Specifications
