Barco UDX User Manual

205R5906112 /15 UDX
Video timing
(active pixels x active
lines)
Vertical refresh rate
(Hz)
Available layout modes,
other than standard
layout (1 x 1 layout)
16
Support for 3D?
1280 x 1600 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1400 x 1050 60
1600 x 1200 60
1600 x 1200 120 Active 3D
1920 x 1080 50
1920 x 1080 60
1920 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1920 x 1200 50
1920 x 1200 60
1920 x 1200 120 4 Quadrant mode (2 x 2
layout)
Active 3D
1920 x 2160 60 2 Column mode (2 x 1
layout)
Passive stereo
1920 x 2160 120 2 Column mode (2 x 1
layout)
Active 3D
1920 x 2400 60 2 Column mode (2 x 1
layout)
2048 x 1080 24
2048 x 1080 25
2048 x 1080 30
2048 x 1080 48
2048 x 1080 50
2048 x 1080 60
2048 x 1080 120 4 Quadrant mode (2 x 2
layout)
Active 3D
2048 x 2160 60 2 Column mode (2 x 1
layout)
2048 x 2160 120 2 Column mode (2 x 1
layout)
Active 3D
2560 x 1080 120 Active 3D
2560 x 1440 120 Active 3D
2560 x 1600 50
2560 x 1600 60
2560 x 1600 120
3840 x 2160 24
Video timing tables
16. Other layout modes are only available on Input boards that have multiple DP inputs.
